File Name:RSP-2400-SPEC 2017-10-31
2400W Power Supply with Single Output
RSP-2400 series
Example 3.2(A): Using external voltage source
Example 3.2(B): Using internal 12V auxiliary output
Example 3.2(C): Using internal 12V auxiliary output
◎ Connection Method
◎ By factory default, and ) on CN2 arePV(PIN3) PS(PIN4
shorted by connector; likewise, andOLP(PIN9) OL-SD(PIN10)
on CN3 are shorted when shipped.
Example 3.2(A) Example 3.2(B) Example 3.2(C)
SW Logic
Power supply output ON SW Open SW Open
SW OpenPower supply output OFF SW Close SW Close
SW Close
3.Remote ON-OFF
※ Remote ON-OFF is activated by the configuration with respect to CN1,CN2 and CN3 as shown in the following diagram.
AUX
12V typ.
12V typ.
12V typ.
Internal
Internal
Internal
AUXG
1KΩ
RCG
RC
SW
12V
1KΩ
RC
RCG
AUXG
AUX
SW
1KΩ
1KΩ
RC
AUXG
SW
RCG
AUX
PIN7 AUXG
PIN8 AUX
CN3
CN2
PIN2 RC
PIN1 RCG
