Hardware Installation - 15 -

Power Supply  2 x 2000W redundant PSUs

 80 PLUS Platinum

 AC Input:

- 100-127V~/ 14A, 47-63Hz

- 200-240V~/ 12.6A, 47-63Hz

 DC Output:

- Max 1200W/ 100-127V~

+12.12V/ 95.6A

+12Vsb/ 3.5A

- Max 2200W/ 200-240V

+12.12V/ 178.1A

+12Vsb/ 3.5A

System power supply requires C19 type power cord

Ambient

Temperature

Relative

Humidity

 Operating temperature: 10°C to 35°C

 Operating humidity: 8-80% (non-condensing)

 Non-operating temperature: -40°C to 60°C

 Non-operating humidity: 20%-95% (non-condensing)

* We reserves the right to make any changes to the product specications and product-related information without prior

notice.
