◎ψ3 3 wire / 230VAC△
◎ψ3 4 wire / Y 400VAC
230V
230V
T
RST-10000
S
R
FG
L1
N1
L2
N2
L3
N3
Fig 1.1
AC Power Connection
Function Manual
Fig 1.1
1.Remote Sense
※ The remote sense function compensates the voltage drop on the cable, between the power supply and the load, up to 0.3V.
LOAD
-V
+V
Sense lines should be twisted in pairs to minimize
noise pick-up.
+V
-V
PIN5 -S
PIN3 +S
10000W Power Supply with Single Output
RST-10000 series
File Name:RST-10000-SPEC 2019-07-16
DIP
SW
CN993
CN992
CN991
T
N
S
R
RST-10000
FG
L1
N1
L2
N2
L3
N3
230V
400V
Fig 1.2
SVR
※ If the remote sense function is not required,+S and +V of the output terminal, as well as -S and -V, need to be connected to be free from noise and
interference. (+S and +V of the output terminal, -S and -V are connected as factory default setting)
