![MEAN WELL RST-10000-24 [5/10] Rst 1000](/img/pdf.png)
MEAN WELL RST-10000-24 [5/10] Rst 1000
![MEAN WELL RST-10000-24 [5/10] Rst 1000](/views2/1681410/page5/bg5.png)
10000W Power Supply with Single Output
RST-10000 series
File Name:RST-10000-SPEC 2019-07-16
Fig 2.2
2.Voltage Adjustment
(a)Have the DIP switch position-3 set as
(a)Have the DIP switch position-3 set as
(b)Output voltage can be trimmed by SVR.
(b)The output voltage can be trimmed to 20~120% of the nominal voltage by applying EXTERNAL VOLTAGE between + and on CN992 or CN993.PV PV-
(1)by potentiometer (SVR)
(2)by Output Voltage Programming*
Nominal Vout
V
12345
6
20
40
60
80
100
120
EXTERNAL VOLTAGE (VDC)
OUTPUT VOLTAGE (%)
Non-Linear
ON
OFF
123
ON
OFF
123
PIN6 PV+PIN4 PV-
EXTERNAL VOLTAGE (DC)
CN993
SVR
Fig 2.1
LOAD
-V
+V
+V
-V
DIP
SW
DIP
SWITCH
CN993
CN992
CN991
SVR
*: or, PV/remote voltage programming / remote adjust / margin programming / dynamic voltage trim.
+S and +V, as well as -S and -V, need to be connected as factory default setting◎
