ASRock H110 Pro BTC+ [7/73] Specifications
![ASRock H110 Pro BTC+ [7/73] Specifications](/views2/1687347/page7/bg7.png)
2
English
1.2 Specications
Platform
•
ATX Form Factor
•
Solid Capacitor design
CPU
•
Supports 7
th
and 6
th
Generation Intel® Core
TM
i7/i5/i3/
Pentium®/Celeron® Processors (Socket 1151)
•
Supports CPU up to 91W
•
Digi Power design
•
8 Power Phase design
•
Supports Intel® Turbo Boost 2.0 Technology
Chipset
•
Intel® H110
Memory
•
Dual Channel DDR4 Memory Technology
•
2 x DDR4 DIMM Slots
•
Supports DDR4 2400/2133 non-ECC, un-buered memory*
* 7
th
Gen Intel® CPU supports DDR4 up to 2400; 6th Gen Intel®
CPU supports DDR4 up to 2133.
•
Supports ECC UDIMM memory modules (operate in non-
ECC mode)
•
Max. capacity of system memory: 32GB
•
Supports Intel® Extreme Memory Prole (XMP) 2.0
•
15μ Gold Contact in DIMM Slots
Expansion
Slot
•
1 x PCI Express 3.0 x16 Slot (PCIE2: x16 mode)*
* Supports NVMe SSD as boot disk
•
12 x PCI Express 2.0 x1 Slots
Graphics
•
Intel® HD Graphics Built-in Visuals and the VGA outputs
can be supported only with processors which are GPU
integrated.
•
Supports Intel® HD Graphics Built-in Visuals : Intel® Quick
Sync Video with AVC, MVC (S3D) and MPEG-2 Full
HW Encode1, Intel® InTru
TM
3D, Intel® Clear Video HD
Technology, Intel® Insider
TM
, Intel® HD Graphics
•
Gen9 LP, DX11.3, DX12
•
HWAEncode/Decode: VP8, HEVC 8b, VP9, HEVC 10b (For
7
th
Gen Intel® CPU)
