![ASRock H110 Pro BTC+ [8/73] Rear panel i o](/views2/1687347/page8/bg8.png)
3
English
H110 Pro BTC+
•
HWA Encode/Decode: VP8 , HEVC 8b; GPU/SWEncode/
Decode: VP9, HEVC 10b (For 6
th
Gen Intel® CPU)
•
Max. shared memory 1024MB
* e size of maximum shared memory may vary from dierent
operating systems.
•
Supports DVI-D with max. resolution up to 1920x1200 @
60Hz
•
Supports Accelerated Media Codecs: HEVC, VP8, VP9
•
Supports HDCP with DVI-D Port
•
Supports Full HD 1080p Blu-ray (BD) playback with DVI-D
Port
Audio
•
7.1 CH HD Audio (Realtek ALC887 Audio Codec)
* To congure 7.1 CH HD Audio, it is required to use an HD
front panel audio module and enable the multi-channel audio
feature through the audio driver.
•
Supports Surge Protection
•
ELNA Audio Caps
LAN
•
Gigabit LAN 10/100/1000 Mb/s
•
Giga PHY Intel® I219V
•
Supports Wake-On-LAN (Supported on Black PCIe Slots
only)
•
Supports Lightning/ESD Protection
•
Supports Energy Ecient Ethernet 802.3az
•
Supports PXE
Rear Panel
I/O
•
1 x PS/2 Mouse Port
•
1 x PS/2 Keyboard Port
•
1 x DVI-D Port
•
4 x USB 2.0 Ports (Supports ESD Protection)
•
2 x USB 3.0 Ports (Supports ESD Protection)
•
1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
•
HD Audio Jacks: Line in / Front Speaker / Microphone
