ASRock H61M-PS4 [24/54] Italian
![ASRock H61M-PS4 [24/54] Italian](/views2/1687981/page24/bg18.png)
24
ASRock H61M-PS4 / H61M-HG4 / H61M-VG4 / H61M-VS4 Motherboard
Speciche
Piattaforma - Micro ATX Form Factor
- Design condensatore compatto
(H61M-PS4 / H61M-HG4 / H61M-VG4)
- Condensatore solido per alimentazione CPU (H61M-VS4)
Processore - Supporta Intel
®
Core
TM
i7 / i5 / i3 / Xeon
®
/ Pentium
®
/ Celeron
®
di 3a e 2a generazione in un pacchetto LGA1155
- Supporto della tecnologia Intel
®
Turbo Boost 2.0
- Supporta CPU unlocked serie K
Chipset - Intel
®
H61
- Supporta tecnologia Intel
®
Rapid Start Technology e Smart
Connect Technology
Memoria - Supporto tecnologia Dual Channel Memory
- 2 x slot DDR3 DIMM
- Supporto DDR3 1600/1333/1066 non-ECC, momoria senza
buffer (DDR3 1600 con CPU Intel
®
Ivy Bridge, DDR3 1333 con
CPU Intel
®
Sandy Bridge)
- Capacità massima della memoria di sistema: 16GB
- Supporto di Intel
®
XMP (Extreme Memory Prole)1.3/1.2 con
CPU Intel
®
Ivy Bridge
Slot di - 1 x Alloggi PCI Express 3.0 x16 (blu a modalità x16)
espansione * PCIE 3.0 è supportato soltanto con la CPU Intel
®
Ivy Bridge.
Con la CPU Intel
®
Sandy Bridge, supporta solamente PCIE
2.0.
- 1 x Alloggi PCI Express 2.0 x1
VGA su scheda * Le uscite Intel
®
HD Graphics Built-in Visuals e VGA possono
essere supportate solo con processori dotati di GPU
integrata.
- Supporta Intel
®
HD Graphics Built-in Visuals: Intel
®
Quick Sync
Video 2.0, Intel
®
InTru
TM
3D, Intel
®
Clear Video HD Technology,
Intel
®
Insider
TM
, Intel
®
HD Graphics 2500/4000 con CPU Intel
®
Ivy Bridge
- Supporta Intel
®
HD Graphics Built-in Visuals: Intel
®
Quick Sync
Video, Intel
®
InTru
TM
3D, Intel
®
Clear Video HD Technology,
Intel
®
HD Graphics 2000/3000, Intel
®
Advanced Vector
Extensions (AVX) con CPU Intel
®
Sandy Bridge
- Pixel Shader 5.0, DirectX 11 con CPU Intel
®
Ivy Bridge, Pixel
Shader 4.1, DirectX 10.1 con CPU Intel
®
Sandy Bridge
- Memoria massima condivisa 1760MB con CPU Intel
®
Ivy Bridge. Memoria massima condivisa 1759MB con CPU
Italiano
