52
ASRock H61M-PS4 / H61M-HG4 / H61M-VG4 / H61M-VS4 Motherboard
Spesikasi
Podium - Faktor Form Mikro ATX
- Desain All Solid Capacitor (H61M-PS4 / H61M-HG4 /
H61M-VG4)
- Kapasitor Solid untuk daya CPU (H61M-VS4)
CPU - Mendukung Intel
®
Core
TM
i7 / i5 / i3 / Xeon
®
/ Pentium
®
/
Celeron
®
Generasi ke-2 dalam paket LGA1155
- Menggunakan Teknologi Intel
®
Turbo Boost 2.0
- Mendukung CPU K-Series jenis “unlocked”
Grup Chip - Intel
®
H61
- Mendukung Intel
®
Rapid Start Technology dan Smart
Connect Technology
Ingatan - Teknologi ingatan DDR3 dwisaluran
- 2 x Alur DDR3 DIMM
- Mendukung memori DDR3 1600/1333/1066 non-ECC yang
tidak di-buffer (DDR3 1600 dengan Intel
®
Ivy Bridge CPU,
DDR3 1333 dengan Intel
®
Sandy Bridge CPU)
- Kapasitas paling banyak: 16GB
- Mendukung Intel
®
Extreme Memory Prole (XMP) dengan
Intel
®
Ivy Bridge CPU
Alur Ekspansi - 1 x slot PCI Express 3.0 x16 (biru @ x16 mode)
* PCIE 3.0 hanya didukung dengan Intel
®
Ivy Bridge CPU.
Dengan Intel
®
Sandy Bridge CPU, hanya PCIE 2.0 yang
didukung.
- 1 x PCI Express 2.0 x1 slot
Diagram * Intel
®
HD Graphics Built-in Visual dan output VGA hanya
dapat didukung dengan prosesor yang mengintegrasikan
GPU.
- Mendukung Intel
®
HD Graphics Built-in Visuals: Intel
®
Quick
Sync Video 2.0, Intel
®
InTru
TM
3D, Intel
®
Clear Video HD
Technology, Intel
®
Insider
TM
, Intel
®
HD Graphics 2500/4000
dengan Intel
®
Ivy Bridge CPU
- Mendukung Intel
®
HD Graphics Built-in Visuals: Intel
®
Quick
Sync Video, Intel
®
InTru
TM
3D, Intel
®
Clear Video HD
Technology, Intel
®
HD Graphics 2000/3000, Intel
®
Advanced
Vector Extensions (AVX) dengan Intel
®
Sandy Bridge CPU
- Pixel Shader 5.0, DirectX 11 dengan Intel
®
Ivy Bridge CPU,
Pixel Shader 4.1, DirectX 10.1 dengan Intel
®
Sandy Bridge
CPU
- Ingatan sama Max. 1760MB dengan Intel
®
Ivy Bridge CPU.
Bahasa Indonesia
