ASRock H61M-PS4 / H61M-HG4 / H61M-VG4 / H61M-VS4 Motherboard
Español
Especicación
Plataforma - Factor forma Micro ATX
- Todo diseño de Capacitor Sólido (H61M-PS4 / H61M-HG4 /
H61M-VG4)
- Condensador sólido para alimentación de CPU (H61M-VS4)
Procesador - Admite procesadores Intel
®
Core
TM
i7 / i5 / i3 / Xeon
®
/
Pentium
®
/ Celeron
®
de la 3ª y 2ª generación en el paquete
LGA1155
- Admite la tecnología Intel
®
Turbo Boost 2.0 Technology
- Admite procesador desbloqueado de la serie K
Chipset - Intel
®
H61
- Admite las tecnologías Intel
®
Rapid Start y Smart Connect
Memoria - Soporte de Tecnología de Memoria de Doble Canal
- 2 x DDR3 DIMM slots
- Apoya DDR3 1600/1333/1066 non-ECC, memoria de
un-buffered (DDR3 1600 con CPU Intel
®
Ivy Bridge,
DDR3 1333 con CPU Intel
®
Sandy Bridge)
- Máxima capacidad de la memoria del sistema: 16GB
- Compatible con Intel
®
Extreme Memory Prole (XMP)1.3/1.2
con la CPU Intel
®
Ivy Bridge
Ranuras de - 1 x ranura PCI Express 3.0 x16 (azul @ modo x16)
Expansión * PCIE 3.0 solamente se admite con una CPU Intel
®
Ivy
Bridge. Con una CPU Intel
®
Sandy Bridge, solamente
admite PCIE 2.0.
- 1 x ranura PCI Express 2.0 x1
VGA OnBoard * Los efectos visuales incorporados con grácos de alta
denición Intel
®
y las salidas VGA sólo se soportan con
procesadores con GPU integrada.
- Admite Intel
®
HD Graphics Built-in Visuals: Intel
®
Quick Sync
Video 2.0, Intel
®
InTru
TM
3D, Intel
®
Clear Video HD
Technology, Intel
®
Insider
TM
, Intel
®
HD Graphics 2500/4000
con la CPU Intel
®
Ivy Bridge
- Admite Intel
®
HD Graphics Built-in Visuals: Intel
®
Quick Sync
Video, Intel
®
InTru
TM
3D, Intel
®
Clear Video HD Technology,
Intel
®
HD Graphics 2000/3000 e Intel
®
Advanced Vector
Extensions (AVX) con la CPU Intel
®
Sandy Bridge
- Pixel Shader 5.0, DirectX 11 con CPU Intel
®
Ivy Bridge, Pixel
Shader 4.1, DirectX 10.1 con CPU Intel
®
Sandy Bridge
- 1760MB de Memoria máxima compartida con la CPU
Intel
®
Ivy Bridge. 1759MB de Memoria máxima compartida
