![ASRock G41M-VS3 R2.0 [11/51] Motherboard l 1 motherboard l 1 motherboard l 1 motherboard l 1 motherboard layout g41m ayout g41m ayout g41m ayout g41m ayout g41m vgs3 g41m vgs3 g41m vgs3 g41m vgs3 g41m vgs3 g41m vs3 vs3 vs3 vs3 vs3](/img/pdf.png)
ASRock G41M-VS3 R2.0 [11/51] Motherboard l 1 motherboard l 1 motherboard l 1 motherboard l 1 motherboard layout g41m ayout g41m ayout g41m ayout g41m ayout g41m vgs3 g41m vgs3 g41m vgs3 g41m vgs3 g41m vgs3 g41m vs3 vs3 vs3 vs3 vs3
![ASRock G41M-VS3 R2.0 [11/51] Motherboard l 1 motherboard l 1 motherboard l 1 motherboard l 1 motherboard layout g41m ayout g41m ayout g41m ayout g41m ayout g41m vgs3 g41m vgs3 g41m vgs3 g41m vgs3 g41m vgs3 g41m vs3 vs3 vs3 vs3 vs3](/views2/1689164/page11/bgb.png)
1111
1111
11
1.3 Motherboard L1.3 Motherboard L
1.3 Motherboard L1.3 Motherboard L
1.3 Motherboard L
ayout (G41M-ayout (G41M-
ayout (G41M-ayout (G41M-
ayout (G41M-
VGS3 / G41M-VGS3 / G41M-
VGS3 / G41M-VGS3 / G41M-
VGS3 / G41M-
VS3)VS3)
VS3)VS3)
VS3)
1 PS2_USB_PWR1 Jumper 15 USB 2.0 Header (USB4_5, Blue)
2 ATX 12V Connector (ATX12V2) 16 Chassis Fan Connector (CHA_FAN1)
3 CPU Fan Connector (CPU_FAN1) 17 USB 2.0 Header (USB6_7, Blue)
4 ATX Power Connector (ATXPWR1) 18 Clear CMOS Jumper (CLRCMOS1)
5 2 x 240-pin DDR3 DIMM Slots 19 BIOS SPI Chip
(Dual Channel: DDR3_A1, DDR3_B1; Blue) 20 PCI Slot (PCI1)
6 North Bridge Controller 21 PCI Express x16 Slot (PCIE1)
7 South Bridge Controller 22 EUP Audio Jumper (EUP_AUDIO1)
8 System Panel Header (PANEL1, White) 23 EUP LAN Jumper (EUP_LAN1)
9 IDE1 Connector (IDE1, Blue) 24 Front Panel Audio Header
10 Primary SATAII Connector (SATAII_1; Blue) (HD_AUDIO1, White)
11 Secondary SATAII Connector (SATAII_2; Blue) 25 Serial Port Connector (COM1)
12 Third SATAII Connector (SATAII_3; Blue) 26 Print Port Header (LPT1, White)
13 Fourth SATAII Connector (SATAII_4; Blue) 27 FSB1 Jumper
14 Chassis Speaker Header (SPEAKER 1, White) 28 775-Pin CPU Socket
1
PS2_USB_PWR1
IDE1
CHA_FAN1
SPEAKER1
1
HD_AUDIO1
Intel
G41
Chipset
CLRCMOS1
PANEL1
HDLED RESET
PLED PWRBTN
1
8Mb
BIOS
1
AUDIO
CODEC
17.0cm (6.7 in)
22.6cm (8.9 in)
ATX12V2
Super
IO
1
24
5
7
6
8
910
12
13
14
11
15
16
17
18
19
3
20
21
Intel
ICH7
FSB800
DDR3_A1 (64 bit, 240-pin module)
FSB800
DDR3_B1 (64 bit, 240-pin module)
SATAII_1SATAII_2
PCIE1
LAN
PHY
USB 2.0
T: U SB2
B: USB3
USB 2.0
T: USB0
B: USB1
Top:
RJ-45
PS2
Mouse
PS2
Keyboard
VGA1
Top:
Line In
Center:
Line Out
Bottom:
Mic In
CPU_FAN1
1
USB6_7
PCI1
1
USB4_5
FSB1333
ErP/
DDR3 1333
Dual Channel
EuP Ready
Designed in Taipei
RoHS
CMOS
Battery
1
LPT1
22
DX10
EUP_LAN
1
EUP_AUDIO1
1
23
SATAII_3SATAII_4
1
FSB1
24
25
26
COM1
1
27
28
