ASRock P4 Combo Инструкция онлайн
Содержание
- P4 combo 1
- User manual 1
- Copyright notice 2
- Disclaimer 2
- Bios setup utility 23 3
- Contents 3
- Installation 10 3
- Introduction 5 3
- Software support 38 4
- Introduction 5
- Package contents 5
- Specifications 6
- Bios ami legal bios supports plug and play acpi 1 compliance wake up events cpu frequency stepless control only for advanced users reference see caution 6 os microsof 7
- Caution 7
- Se me 2000 xp compliant 7
- Window 7
- 14 15 16 17 18 19 20 21 8
- 2 5 4 3 8
- 23 24 25 8
- Atx12v1 8
- Atxpwr1 8
- Audio1 8
- Aux1 cd1 8
- Bottom mic in 8
- Center line out 8
- Cha_fan1 8
- Clrcmos0 8
- Cmos battery 8
- Cpu_fan1 8
- Ddr1 64 72 bit 184 pin module 8
- Ddr2 64 72 bit 184 pin module 8
- Ddr400 agp8x 8
- Floppy1 8
- Fsb800 8
- Intel 848p chipset 8
- Intel ich5 chipset 8
- J13 j12 8
- J5 j9 j6 j10 8
- J8 j18 8
- Jr1 jl1 8
- Lan chip 8
- Mb bios 8
- Motherboard layout 8
- P4 combo 8
- Panel 1 8
- Parallel port 8
- Pga478 8
- Prescott 800 8
- Ps2 keyboard 8
- Ps2 mouse 8
- Ps2_usb_pwr1 8
- Speaker1 8
- Super i o 8
- Top line in 8
- Top rj 45 8
- Usb 2 t usb0 b usb1 8
- Usb 2 t usb2 b usb3 8
- Usb 2 t usb4 b usb5 8
- Usb2 5 ch 8
- Usb4_5 8
- V_agp1 8
- 7 8 9 10 11 9
- Asrock i o plu 9
- J1 j6 jumpers j8 j13 jumpers j18 j21 jumpers 9
- Magnification of no 6 on page 8 9
- Installation 10
- Pre installation precautions 10
- Cpu sockets 11
- Cpu type jumper settings 11
- For clearer view of jumpers j1 j6 j8 j13 11
- J13 j12 11
- J18 and j21 please re fer to the magnification 11
- J5 j9 j6 j10 11
- J8 j18 11
- On page 9 11
- This motherboard is equipped with two types of cpu sockets you may choose to install either intel 775 pin cpu or intel 478 pin cpu into this motherboard however to avoid instability and damage to the system please do not install both of them into this motherboard important if you install a 775 pin cpu into this motherboard it is necessary to adjust the setting of j1 j6 j8 j14 j17 j18 and j21 jumpers by shorting pin1 and pin2 of all these 16 sets of jumpers these jumpers are set to support 478 pin cpu by shorting pin2 and pin3 by default please refer to the figure below for these jumpers location on the motherboard 11
- Cpu installation 12
- Installation of cpu fan and heatsink 15
- Installation of memory modules dimm 16
- Expansion slots pci and agp slots 17
- Installing an expansion card 17
- Jumpers setup 18
- Onboard headers and connectors 19
- Serial ata sata hard disks installation 22
- Bios menu bar 23
- Bios setup utility 23
- Introduction 23
- Bios setup utility 24
- Main advanced h w monitor boot security exit 24
- Main screen 24
- Navigation keys 24
- Please check the following table for the function description of each navigation key 24
- System overview 24
- System time hour minute second use this item to specify the system time system date day month date year use this item to specify the system date 24
- To jump to the exit screen or exit the current screen 24
- V02 4 c copyright 1985 2003 american megatrends inc 24
- When you enter the bios setup utility the main screen will appear and display the system overview 24
- Advanced 25
- Advanced screen 25
- Bios setup utility 25
- Cpu configuration 25
- Cpu host frequency while entering setup bios auto detects the present cpu host frequency of this motherboard the actual cpu host frequency will show in the following item spread spectrum this item should always be disabled for better system stability 25
- In this section you may set the configurations for the following items cpu configuration chipset configuration acpi configuration ide configuration pcipnp configuration floppy configuration superio configuration and usb configuration 25
- Setting wrong values in this section may cause the system to malfunction 25
- V02 4 c copyright 1985 2003 american megatrends inc 25
- Advanced 26
- Bios setup utility 26
- Chipset configuration 26
- Dram frequency if auto is selected the motherboard will detect the memory module s inserted and assigns appropriate frequency automatically you may also select other value as operating frequency 133mhz ddr 266 166mhz ddr 333 200mhz ddr 400 26
- Processor that supports hyper threading technology and an operating sys tem that includes optimization for this technology such as microsof 26
- Ratio status this is a read only item which displays whether the ratio status of this motherboard is locked or unlocked if it shows unlocked you will find an item ratio cmos setting appears to allow you changing the ratio value of this motherboard if it shows locked then the item ratio cmos set ting will be hidden if you use the ratio value to time the cpu frequency it will be equal to the core speed of the installed processor ratio actual value this is a read only item which displays the ratio actual value of this motherboard cpu thermal throttling you may select enabled to enable p4 cpu internal thermal control mecha nism to keep the cpu from overheated hyper threading technology to enable this feature it requires a computer system with an intel pentiu 26
- V02 4 c copyright 1985 2003 american megatrends inc 26
- Win dow 26
- Window 26
- Xp or linux kernel version 2 8 or higher this option will be hidden if the installed cpu does not support hyper threading technology 26
- Xp set to auto if using microsof 26
- Acpi configuration 28
- Acpi settings 28
- Advanced 28
- Bios setup utility 28
- Suspend to ram use this item to select whether to auto detect or disable the suspend to ram feature select auto will enable this feature if the os supports it restore on ac power loss use this item to set the power state after an unexpected ac power loss if power off is selected the ac power remains off when the power recovers if power on is selected the ac power resumes and the sys tem starts to boot up when the power recovers ring in power on use this item to enable or disable ring in signals to turn on the system from the power soft off mode pci devices power on use this item to enable or disable pci devices to turn on the system from the power soft off mode ps 2 keyboard power on use this item to enable or disable ps 2 keyboard to turn on the system from the power soft off mode rtc alarm power on use this item to enable or disable rtc real time clock to power on the system 28
- V02 4 c copyright 1985 2003 american megatrends inc 28
- Because inte 29
- Ich5 south bridge only supports four ide devices 29
- Ide configuration 29
- Is used with legacy os 29
- Onboard ide operate mode please select compatible mode when you install legacy os windows me 98se into sata device if you install legacy os into ide hdd while sata devices are used you also need to select compatible mode if native os windows 2000 xp is installed into sata device please select enhanced mode you also need to select enhanced mode while native os is installed into ide hdd and sata devices are used if you do not install any sata device please also select enhanced mode no matter you use legacy os or native os for the system please note that the following options will be varied depending on the onboard ide operate mode compatible mode or enhanced mode that you selected when enhanced mode is selected onboard ide controller you may enable either the primary ide channel or the secondary ide channel or you may enable both the primary and the secondary ide channels by selecting both set to disabled will disable the both configuration options disabled primary secondary both when co 29
- Under legacy os windows me 98se you have to choose either pri ide sata or sata sec ide when the installed sata device 29
- Advanced 30
- After selecting the hard disk information into bios use a disk utility such as fdisk to partition and format the new ide hard disk drives this is necessary so that you can write or read data from the hard disk make sure to set the partition of the primary ide hard disk drives to active 30
- Bios setup utility 30
- Ide device configuration you may set the ide configuration for the device that you specify we will use the primary ide master as the example in the following instruction which can be applied to the configurations of primary ide slave sec ondary ide master secondary ide slave sata1 and sata2 as well 30
- Mb under dos and windows for netware and unix user select disabled to disable the lba large mode 30
- Primary ide master 30
- Select screen select item change option f1 general help f9 load defaults f10 save and exit esc exit 30
- Select the type of device connected to the system 30
- Type use this item to configure the type of the ide device that you specify configuration options not installed auto cd dvd and armd not installed select not installed to disable the use of ide device auto select auto to automatically detect the hard disk drive 30
- V02 4 c copyright 1985 2003 american megatrends inc 30
- Pcipnp configuration 31
- Advanced 32
- Bios setup utility 32
- Configure super io chipset 32
- Floppy configuration 32
- In this section you may configure the type of your floppy drive 32
- Onboard floppy controller use this item to enable or disable floppy drive controller serial port address use this item to set the address for the onboard serial port or disable it configuration options disabled 3f8 irq4 2f8 irq3 3e8 irq4 2e8 irq3 infrared port address use this item to set the address for the onboard infrared port or disable it configuration options disabled 2f8 irq3 and 2e8 irq3 32
- Super io configuration 32
- V02 4 c copyright 1985 2003 american megatrends inc 32
- Advanced 34
- Bios setup utility 34
- Hardware health event monitoring 34
- Hardware health event monitoring screen 34
- In this section it allows you to monitor the status of the hardware on your system including the parameters of the cpu temperature motherboard temperature cpu fan speed chassis fan speed and the critical voltage 34
- Main advanced boot security exit h w monitor 34
- Usb configuration 34
- Usb controller use this item to enable or disable the use of usb controller usb 2 support use this item to enable or disable the usb 2 support legacy usb support use this item to enable or disable the support to emulate legacy i o devices such as mouse keyboard etc or you may select auto so that the system will start to auto detect if there is no usb device connected auto option will disable the legacy usb support 34
- V02 4 c copyright 1985 2003 american megatrends inc 34
- Bios setup utility 35
- Boot from network use this item to enable or disable the boot from network feature boot up num lock if this item is set to on it will automatically activate the numeric lock function after boot up 35
- Boot screen 35
- Boot settings 35
- Boot settings configuration 35
- In this section it will display the available devices on your system for you to config ure the boot settings and the boot priority 35
- Main advanced h w monitor security exit 35
- V02 4 c copyright 1985 2003 american megatrends inc 35
- Bios setup utility 36
- Boot device priority 36
- In this section you may set or change the supervisor user password for the system for the user password you may also clear it 36
- In this section you may specify the boot sequence from the available devices in your system 36
- Likewise you may also specify the boot sequence from the available devices for the hard disk drives the removable drives and the cd dvd drives 36
- Security screen 36
- V02 4 c copyright 1985 2003 american megatrends inc 36
- Bios setup utility 37
- Exit options 37
- Exit screen 37
- Main advanced h w monitro boot security 37
- Save changes and exit when you select this option it will pop out the following message save configuration changes and exit setup select ok to save the changes and exit the bios setup utility discard changes and exit when you select this option it will pop out the following message dis card changes and exit setup select ok to exit the bios setup utility without saving any changes discard changes when you select this option it will pop out the following message dis card changes select ok to discard all changes load optimal defaults when you select this option it will pop out the following message load optimal defaults select ok to load the default values for all the setup configurations 37
- V02 4 c copyright 1985 2003 american megatrends inc 37
- Asrock pc diy live demo program 38
- Chapter 4 software support 38
- Contact information 38
- Drivers menu 38
- Install operating system 38
- Lga 775 cpu installation live demo program 38
- Running the support cd 38
- Support cd information 38
- Utilities menu 38
