ASRock PE PRO-HT [7/25] Asrock i
![ASRock PE PRO-HT [7/25] Asrock i](/views2/1690218/page7/bg7.png)
7
1.4 ASRock I/O
TM
1 Parallel port 6 Line Out (Lime)
2 RJ-45 port 7 USB 2.0 ports
3 Game port 8 Serial port (COM1)
4 Microphone (Pink) 9 PS/2 keyboard port (Purple)
5 Line In (Light Blue) 10 PS/2 mouse port (Green)
12
3
4567
8
910
