Chapter 2 Installation

PE Pro-HT is an ATX form factor (12" x 9.6", 30.5 x 24.4 cm) motherboard. Before

you install the motherboard, study the configuration of your chassis to ensure that

the motherboard fits into it.

Make sure to unplug the power cord before installing or removing the

motherboard. Failure to do so may cause physical injuries to you

and damages to motherboard components.

2.1 Screw Holes

Place screws into the holes indicated by circles to secure the motherboard

to the chassis.

Do not over-tighten the screws! Doing so may damage the

motherboard.

2.2 Pre-installation Precautions

Take note of the following precautions before you install motherboard components

or change any motherboard settings.

1. Unplug the power cord from the wall socket before touching any component.

2. To avoid damaging the motherboard components due to static electricity, NEVER

place your motherboard directly on the carpet or the like. Also remember to use

a grounded wrist strap or touch a safety grounded object before you handle

components.

3. Hold components by the edges and do not touch the ICs.

4. Whenever you uninstall any component, place it on a grounded antistatic pad or

in the bag that comes with the component.

Before you install or remove any component, ensure that the power is switched

off or the power cord is detached from the power supply. Failure to do so may cause

severe damage to the motherboard, peripherals, and/or components.

2.3 CPU Installation

Step 1. Unlock the socket by lifting the lever up to a 90 angle.

Step 2. Position the CPU directly above the socket such that its marked corner

matches the base of the socket lever.

Step 3. Carefully insert the CPU into the socket until it fits in place.
