Fatal1ty B450 Gaming-ITX/ac Series
3
English
* Supports PCIe riser cards to extend one x16 slot to two x8 slots
if you install AMD Ryzen series CPUs
* Supports NVMe SSD as boot disks
•
1 x Vertical M.2 Socket (Key E) with the bundled WiFi-
802.11ac module (on the rear I/O)
•
15μ Gold Contact in VGA PCIe Slot (PCIE1)
Graphics
•
Integrated AMD Radeon
TM
Vega Series Graphics in Ryzen
Series APU*
* Actual support may vary by CPU
•
DirectX 12, Pixel Shader 5.0
•
Max. shared memory 2GB
•
Dual graphics output: Support HDMI and DisplayPort 1.2 by
independent display controllers
•
Supports HDMI with max. resolution up to 4K x 2K
(4096x2160) @ 60Hz
•
Supports DisplayPort 1.2 with max. resolution up to 4K x 2K
(4096x2160) @ 60Hz
•
Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and
HBR (High Bit Rate Audio) with HDMI Ports (Compliant
HDMI monitor is required)
•
Supports HDCP with HDMI and DisplayPort 1.2 Ports
•
Supports 4K Ultra HD (UHD) playback with HDMI and
DisplayPort 1.2 Ports
Audio
•
7.1 CH HD Audio with Content Protection (Realtek ALC1220
Audio Codec)
•
Premium Blu-ray Audio support
•
Supports Surge Protection
•
Nichicon Fine Gold Series Audio Caps
•
120dB SNR DAC with Dierential Amplier
•
Pure Power-In
•
Direct Drive Technology
•
PCB Isolate Shielding
•
Impedance Sensing on Line Out port
•
Individual PCB Layers for R/L Audio Channel
•
Gold Audio Jacks
•
Supports Creative SoundBlaster Cinema5
