ASRock Fatal1ty B450 Gaming-ITX/ac [36/92] English
![ASRock Fatal1ty B450 Gaming-ITX/ac [36/92] English](/views2/1690513/page36/bg24.png)
English
28
e DIMM only ts in one correct orientation. It will cause permanent damage to
the motherboard and the DIMM if you force the DIMM into the slot at incorrect
orientation.
1
2
3
