9
English
X370M-HDV R4.0 / AB350M-HDV R4.0 / A320M-HDV R4.0 / A320M-DVS R4.0
Expansion
Slot
AMD Ryzen series CPUs (Matisse, Summit Ridge and
Pinnacle Ridge)
•
1 x PCI Express 3.0 x16 Slot (PCIE2: x16 mode)*
AMD 7
th
A-Series APUs
•
1 x PCI Express 3.0 x16 Slot (PCIE2: x8 mode)*
AMD Ryzen series CPUs (Picasso, Raven Ridge)
•
1 x PCI Express 3.0 x16 Slot (PCIE2: x8 mode)*
AMD Athlon series CPUs
•
1 x PCI Express 3.0 x16 Slot (PCIE2: x4 mode)*
* Supports NVMe SSD as boot disks
•
1 x PCI Express 2.0 x1 Slot
Graphics
•
Integrated AMD Radeon
TM
Vega Series Graphics in Ryzen
Series APU*
•
Integrated AMD Radeon
TM
R-Series Graphics in A-series
APU*
* Actual support may vary by CPU
•
DirectX 12, Pixel Shader 5.0
•
Shared memory default 2GB, Max Shared memory supports
up to 16GB.
* e Max shared memory 16 GB requires 32 GB system memory
installed.
X370M-HDV R4.0 / AB350M-HDV R4.0 / A320M-HDV R4.0
only:
•
ree graphics output options: D-Sub, DVI-D and HDMI
•
Supports Triple Monitor
•
Supports HDMI 1.4 with max. resolution up to 4K x 2K
(4096x2160) @ 24Hz / (3840x2160) @ 30Hz
•
Supports DVI-D with max. resolution up to 1920x1200 @
60Hz
•
Supports D-Sub with max. resolution up to 2048x1536 @
60Hz
•
Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and
HBR (High Bit Rate Audio) with HDMI 1.4 Port (Compliant
HDMI monitor is required)
•
Supports HDCP 1.4 with DVI-D and HDMI 1.4 Ports
•
Supports Full HD 1080p Blu-ray (BD) playback with DVI-D
and HDMI 1.4 Ports
