ASRock A320M-DVS R4.0 [17/76] English
![ASRock A320M-DVS R4.0 [17/76] English](/views2/1691297/page17/bg11.png)
15
English
X370M-HDV R4.0 / AB350M-HDV R4.0 / A320M-HDV R4.0 / A320M-DVS R4.0
Ryzen Series CPUs (Matisse):
Ryzen Series CPUs (Picasso):
Ryzen Series CPUs (Summit Ridge):
Ryzen Series CPUs (Raven Ridge):
UDIMM Memory Slot
Frequency
(Mhz)
A1 B1
SR - 3200
- SR 3200
DR - 3200
- DR 3200
SR SR 3200
DR DR 3200
UDIMM Memory Slot
Frequency
(Mhz)
A1 B1
SR - 2933
- SR 2933
DR - 2667
- DR 2667
SR SR 2933
DR DR 2667
UDIMM Memory Slot
Frequency
(Mhz)
A1 B1
SR - 2667
- SR 2667
DR - 2667
- DR 2667
SR SR 2667
DR DR 2667
UDIMM Memory Slot
Frequency
(Mhz)
A1 B1
SR - 2933
- SR 2933
DR - 2667
- DR 2667
SR SR 2667
DR DR 2400
SR: Single rank DIMM, 1Rx4 or 1Rx8 on DIMM module label
DR: Dual rank DIMM, 2Rx4 or 2Rx8 on DIMM module label
