29
Deutsch
X370M-HDV R4.0 / AB350M-HDV R4.0 / A320M-HDV R4.0 / A320M-DVS R4.0
•
Unterstützt HDCP 1.4 mit DVI-D-Port
•
Unterstützt Blu-ray- (BD) Wiedergabe (Full HD/1080p) mit
DVI-D-Port
Audio
•
7.1-Kanal-HD-Audio (Realtek ALC887/897-Audiocodec)
•
Unterstützt Überspannungsschutz
LAN
•
PCIE-x1-Gigabit-LAN 10/100/1000 Mb/s
•
Realtek RTL8111H
•
Unterstützt Wake-On-LAN
•
Unterstützt Schutz gegen Blitzschlag/elektrostatische Entladung
•
Unterstützt energieezientes Ethernet 802.3az
•
Unterstützt PXE
Rückblende,
E/A
•
1 x PS/2-Maus-/Tastaturanschluss
•
2 x USB-2.0-Ports (unterstützt Schutz gegen elektrostatische
Entladung)
•
4 x USB-3.2-Gen1-Ports (unterstützt Schutz gegen elektrosta-
tische Entladung)
•
1 x RJ-45-LAN-Port mit LED (Aktivität/Verbindung-LED und
Geschwindigkeit-LED)
•
HD-Audioanschlüsse: Line-in / Vorderer Lautsprecher / Mikro-
fon
X370M-HDV R4.0 / AB350M-HDV R4.0 / A320M-HDV R4.0:
•
1 x D-Sub-Port
•
1 x DVI-D-Port
•
1 x HDMI-Port
A320M-DVS R4.0:
•
1 x D-Sub-Port
•
1 x DVI-D-Port
Speicher
•
4 x SATA-III-6,0-Gb/s-Anschlüsse, unterstützt RAID (RAID 0,
RAID 1 und RAID 10), NCQ, AHCI und Hot-Plugging
•
1 x Ultra-M.2-Sockel, unterstützt M-Key-Typ-2242/2260/2280-
M.2-SATA-III-6,0-Gb/s-Modul und M.2-PCI-Express-Modul
bis Gen3 x 4
(32 Gb/s) (mit Matisse, Picasso, Summit Ridge, Raven Ridge
und Pinnacle Ridge) oder Gen3 x 2 (16 Gb/s) (mit APU der
A-Serie und Athlon-series-APU)* (nur beim X370M-HDV R4.0
/ AB350M-HDV R4.0 / A320M-HDV R4.0)
* Unterstützt NVMe-SSD als Bootplatte
* Unterstützt ASRock U.2-Kit
Anschluss
•
1 x COM-Anschluss-Stileiste
•
1 x TPM-Stileiste
•
1 x Gehäuseeingri- und Lautsprecher-Stileiste
•
1 x CPU-Lüeranschluss (4-polig)
•
2 x Gehäuselüeranschlüsse (1 x 4-polig, 1 x 3-polig)
* Der CPU-Lüeranschluss unterstützt einen CPU-Lüer mit einer
maximalen Lüerleistung von 1 A (12 W).
•
1 x 24-poliger ATX-Netzanschluss
•
1 x 4-poliger 12-V-Netzanschluss
•
1 x Audioanschluss an Frontblende
•
2 x USB 2.0-Stileisten (unterstützt 4 USB 2.0-Ports) (unterstützt
Schutz gegen elektrostatische Entladung)
•
1 x USB 3.2 Gen1-Stileiste (unterstützt zwei USB 3.2 Gen1-
Ports) (unterstützt Schutz gegen elektrostatische Entladung)
Betriebssys-
tem
•
Microso® Windows® 10, 64 Bit
