MEAN WELL HBG-240-24 [2/9] Hbg 24

File Name:HBG-240-SPEC 2016-12-15

10A

6.7A

240W

150mVp-p

250mVp-p

4.0A

240W

350mVp-p

6 ~ 10A

4.0 ~ 6.7A

3 ~ 5A

2.4 ~ 4.0A

2.5A / 115VAC 1.3A / 230VAC 1.2A / 277VAC

27 ~ 34V

43 ~ 52V

52 ~ 63V

62 ~ 85V

UL8750,CSA C22.2 No.250.13-12, ENEC EN61347-1, P P approvedEN61347-2-13 independent, EN62384; I 65 I 67or

2.1Kg; 8pcs/18.3Kg/2.09CUFT

SPECIFICATION

HBG-240 series

CONSTANT CURRENT REGION

Note.2

MODEL

DC VOLTAGE

RATED CURRENT

RATED POWER

Note.5

OUTPUT

VOLTAGE RANGE

Note.5

FREQUENCY RANGE

POWER FACTOR

EFFICIENCY (Typ.)

AC CURRENT (Typ.)

INPUT

INRUSH CURRENT (Typ.)

LEAKAGE CURRENT

SAFETY STANDARDS

WORKING HUMIDITY

STORAGE TEMP., HUMIDITY

TEMP. COEFFICIENT

VIBRATION

MTBF

DIMENSIONOTHERS

NOTE

PACKING

OVER CURRENT

OVER VOLTAGE

OVER TEMPERATURE

90 ~ 305VAC 127 ~ 431VDC

47 ~ 63Hz

COLD START 75A(twidth= s measured at 50% Ipeak) at 230VAC680μ;Per NEMA 410

<0.75mA / 277VAC

95 ~ 108%

Constant current limiting, recovers automatically after fault condition is removed

20 ~ 95% RH non-condensing

-40 ~ +80 , 10 ~ 95% RH℃

±℃ ℃0.03%/ (0 ~ 50 )

10 ~ 500Hz, 5G 12min./1cycle, period for 72min. each along X, Y, Z axes

663.8K hrs min. Telcordia SR-332 (Bellcore) ; 190.7Khrs min. MIL-HDBK-217F (25 )℃

1. All parameters NOT specially mentioned are measured at 230VAC input, rated current and 25 of ambient temperature.℃

2. Please refer to "DRIVING METHODS OF LED MODULE".

3. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.

4. Tolerance : includes set up tolerance, line regulation and load regulation.

De rating may be needed under low input voltages. Please .- refer to STATIC CHARACTERISTIC sections for details

6. Length of set up time is measured at cold first start. Turning ON/OFF the driver may lead to increase of the set up time.

7. The driver is considered as a component that will be operated in combination with final equipment. Since EMC performance will be affected

by the complete installation, the final equipment manufacturers must re-qualify EMC Directive on the complete installation again.

8. The model certified for CCC(GB19510.14, GB19510.1, GB17743 and GB17625.1) is an optional model . Please contact MEAN WELL for details.

9.To fulfill requirements of the latest ErP regulation for lighting fixtures, this LED driver can only be used behind a switch without permanently

connected to the mains.

10. This series meets the typical life expectancy of >50,000 hours of operation when Tcase, particularly tc point (or TMP, per DLC), is about 70 or less.℃

11. Please refer to the warranty statement on MEAN WELL's website at http://www.meanwell.com

Shut down and latch off o/p voltage, re-power on to recover

ENVIRONMENT

SAFETY &

EMC

PROTECTION

Shut down o/p voltage, recovers automatically after temperature goes down

EMC IMMUNITY

EMC EMISSION 8

Note.

WITHSTAND VOLTAGE

ISOLATION RESISTANCE

I/P-O/P:3.75KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC

I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25 / 70% RH℃

Compliance to EN55015, EN61000-3-2 Class C ( ) ; EN61000-3-3@load 75%≧

Compliance to EN61000-4-2,3,4,5,6,8,11, EN61547,light industry level ( )surge immunity:Line-Earth:4KV,Line-Line:2KV

CURRENT ADJ. RANGE

TOTAL HARMONIC DISTORTION

MAX. No. of PSUs on 16A

CIRCUIT BREAKER

2 units (circuit breaker of type B) / 3 units (circuit breaker of type C) at 230VAC

(Please refer to "STATIC CHARACTERISTIC" section)

PF>0.98/115VAC, PF>0.95/230VAC, PF>0.93/277VAC full load@

(Please refer to " " )POWER FACTOR (PF) CHARACTERISTIC section

THD< 20%(@load 60%/115VC,230VAC; @load 80%/277VAC)≧≧

(Please refer to “TOTAL HARMONIC DISTORTION(THD)” section)

SHORT CIRCUIT

Hiccup mode, recovers automatically after fault condition is removed

WORKING TEMP.

Tcase=-40 ~ +75 (Please refer to “ OUTPUT LOAD vs TEMPERATURE” section)℃

MAX. CASE TEMP.

Tcase=+75℃

240W Constant Voltage + Constant Current LED Driver

LINE REGULATION

LOAD REGULATION

SETUP, RISE TIME

Note.6

HOLD UP TIME (Typ.)

RIPPLE & NOISE (max.)

Note.3

VOLTAGE TOLERANCE

Note.4

500ms,120ms /230VAC 2500ms,120ms /115VAC

15ms /115VAC, 230VAC

±2.0%

±0.5%

24V

14.4 ~ 24V

HBG-240-24

36V

21.6 ~ 36V

HBG-240-36

60V

36 ~ 60V

HBG-240-60

48V

28.8 ~ 48V

HBG-240-48

Adjustable for A-Type (via built-in potentiometer)

92.5%

93.5%

93%

ψ191.5mm *69mm (D * H)
