HBG-240 series
File Name:HBG-240-SPEC 2016-12-15
240W Constant Voltage + Constant Current LED Driver
INSTALLATIONS
Caution
Hanger
High Bay Light
Chain
Please inspect the appearance of the driver if the package is damaged. There should not
be any cracks.
Please do not drop or bump the driver.
All screws including the suspension screw should be paired with a spring washer and locked tight.
The entire luminaire, including the driver, should be limited to 15Kg or less.
The luminaire should be cautiously protected from damage due to shock throughout packaging and transportation.
Please thoroughly follow the preceding cautionary notes to prevent the luminaire from falling, leading to injuries.
