20
Appendix: Advanced BIOS Setup
This section will introduce you the following BIOS Setup menus: “Advanced,”
“Security,” “Power,” “Boot,” and “Exit.”
1. Advanced BIOS Setup Menu
CPU Host Frequency:
[By Jumper]: It is recommended to select this option, which will let the CPU
host frequency of this motherboard determined by the jumper-setting.
[Manual]: This allows user to set CPU host frequency manually. However,
this is not recommended unless user thoroughly knows the feature.
Wrong setup may cause problems during operation.
DRAM Frequency:
If set to [Auto], the motherboard detects the memory module(s) inserted and
automatically assigns appropriate frequency. You may select other value as
operating frequency: [100MHz <DDR 200>], [133MHz <DDR 266>],
[166MHz <DDR 333>], [200MHz <DDR 400>].
Spread Spectrum:
This field should always be [Disabled] for better system stability.
AMIBIOS SETUP UTILITY - VERSION 3.31a
Main
Advanced
Security
Power
Boot
Exit
CPU Host Frequency
Actual Frequency
DRAM Frequency
Spread Spectrum
Chipset Configuration
Resource
Peripheral
System Hardware Monitor
Configuration
Configuration
[ Setup Help ]
133MHz
Auto
Disabled
<Enter> to select how
tosettheCPUhost
frequency.
F1:Help
Esc:Exit
F9:Setup Defaults
F10:Save & Exit
+/-:Change Values
Enter:Select
Sub-Menu
:Select Item
:Select Menu
By Jumper
