23
OnBoard FDC: Use this to enable or disable floppy drive controller.
OnBoard Serial Port: Use this to set addresses for the onboard serial ports or
disable serial ports. Configuration options: [Auto], [Disabled], [3F8 / IRQ4 /
COM1], [2F8 / IRQ3 / COM2], [3E8 / IRQ4 / COM3], [2E8 / IRQ3 / COM4].
OnBoard Infrared Port: This allows you to enable or disable the onboard
infrared port feature. Select [Enabled] will enable this feature if the infrared
module is installed.
OnBoard Parallel Port: Select Parallel Port address or disable Parallel Port.
Configuration options: [Auto], [Disabled], [378], [278].
Parallel Port Mode: Set the operation mode of the parallel port.
OnBoard Midi Port: Select address for Midi Port or disable Midi Port.
Configuration options: [Disabled], [330], [300], [290], [292].
Midi IRQ Select: Use this to select Midi IRQ. Configuration options: [3], [4],
[5], [7], [10], [11].
OnBoard Game Port: Select address for Game Port or disable Game Port.
Configuration options: [Disabled], [200], [208].
OnBoard IDE: You may enable either the primary IDE channel or the secondary
IDE channel. Or you may enable both the primary and the secondary IDE
channels by selecting [Both]. Set to [Disabled] will disable the both.
Configuration options: [Disabled], [Primary], [Secondary], [Both].
OnBoard LAN: This allows you to enable or disable the onboard LAN feature.
OnBoard AC’97 Audio: Select [Disabled], [Auto] or [Enabled] for the onboard
AC’97 Audio feature.
System Hardware Monitor: You can check the status of the hardware on
your system. It allows you to monitor the parameters for CPU temperature,
Motherboard temperature, CPU fan speed, and critical voltage.
AMIBIOS SETUP UTILITY - VERSION 3.31a
Advanced
CPU Temperature
M/B
CPU FAN Speed
Chassis
Vcore
+ 3.30V
+ 5.00V
Temperature
FAN Speed
+ 12.00V
[ Setup Help ]
F1:Help
Esc:Previous Menu
F9:Setup Defaults
F10:Save & Exit
+/-:Change Values
Enter:Select
Sub-Menu
:Select Item
System Hardware Monitor
35C/95F
27C/ 82F
3110 RPM
0RPM
1.728 V
3.312 V
4.975 V
12.167 V
