Voltage monitoring: +12V, +5V, +3V, Vcore;

CPU fan tachometer;

Chassis fan tachometer

PCI slots: 5 slots with PCI Specification 2.2

AGP slot: 1 universal AGP slot,

supports 3.3v / 1.5v, 4X / 2X / 1X AGP cards

AMR slot (optional): 1 slot, supports ASRock MR card, shares the bracket with

the slot PCI 5

USB 2.0: 4 default USB ports and 1 extra set of header for two

additional USB ports upgrade

ASRock I/O

: PS/2: 1 keyboard port / 1 mouse port;

1 RJ 45 port;

4 rear default USB ports (USB 2.0);

1 serial port: COM 1;

1 parallel port: ECP/EPP support;

Audio Jack: Line Out/ Line In/ Microphone + Game port

BIOS: AMI legal BIOS;

Supports “Plug and Play”;

ACPI 1.1 compliance wake up events;

Supports jumperfree;

SMBIOS 2.3.1 support;

CPU frequency stepless control

(only for advanced users’ reference)

OS: Microsoft

Windows

98 SE / ME / 2000 / XP compliant

1. While CPU overheat is detected, the system will automati-

cally shutdown and the power button on the chassis will be

disabled. Please check if the CPU fan on the motherboard

functions properly before you resume the system.

2. Although K7VT2 offers stepless control, it is not recom-

mended to perform over clocking. Frequencies other than

the recommended CPU bus frequencies may cause the

instability of the system or damage the CPU.
