1.3 Motherboard Layout1.3 Motherboard Layout
1.3 Motherboard Layout1.3 Motherboard Layout
1.3 Motherboard Layout
1 ATX power connector (ATXPWR1) 14 Infrared module connector (IR1)
2 CPU socket 15 External speaker connector (SPEAKER 1)
3 CPU fan connector (CPU_FAN1) 16 South Bridge controller
4 North Bridge controller 17 Clear CMOS (CLRCMOS1)
5 184-pin DDR DIMM slots (blue) 18 PCI slots
6 168-pin SDRAM DIMM slots (black) 19 Audio CODEC
7 Primary IDE connector (IDE1, blue) 20 Front panel audio connector (AUDIO1)
8 Secondary IDE connector (IDE2, black) 21 LAN PHY
9 Chassis fan connector (CHA_FAN1) 22 AGP slot
10 Floppy connector (FLOPPY1) 23 FSB_SEL1 jumper
11 Flash EEPROM 24 Internal audio connector: AUX1 (white)
12 System panel connector (PANEL1) 25 Internal audio connector: CD1 (black)
13 USB header (USB45) 26 PS2_USB_PWR1 jumper
27 AMR slot (Optional)
10 32
VIA
KT266A
Chipset
PS2_USB_PWR1
10 32
DDR DIMM1 (64/72 bit, 184-pin module)
Accelerated Graphics Port
DDR DIMM2 (64/72 bit, 184-pin module)
SDR DIMM1 (64 bit, 168-pin module)
SDR DIMM2 (64 bit, 168-pin module)
IDE1
IDE2
CHA_FAN1
2MB
BIOS
USB45
PLED RST
IR1
CMOS
Battery
PCI 1
PCI 2
PCI 3
PCI 4
K7VT2
PCI 5
30.5cm (12.0 in)
24.4cm (9.6 in)
Super
I/O
HDLED PWRBTN
Audio CODEC
LAN PHY
AUX1
Mic
In
GAME AUDIO1
CD1
USB01
LAN
USB23
Mic in
Line out
GAME AUDIO1
PARALLEL PORT
PS/2
PS/2
Mouse
Keyword
COM1
VIA
South
Bridge
FSB_SEL1
Audio1
CPU_FAN1
PANEL1
Speaker1
USB45
1
1
Line
In
Line in
1
2
3
45 6
7
8
9
FLOPPY1
10
11
1213
14
13
15
16
18
19
20
21
22
23
24
25
26
17
CLRCMOS1
AMR1
27
