ASRock K7Upgrade-600 Motherboard

1.2 Specifications1.2 Specifications

1.2 Specifications

Platform: ATX Form Factor: 12.0-in x 8.2-in, 30.5 cm x 20.8 cm

CPU: 462-Pin Socket Supporting AMD Athlon

/ Athlon

XP / Duron

/ 32-bit Sempron Processor

Chipsets: North Bridge:

VIA KT600, FSB @ 400 MHz

South Bridge:

VIA VT8237, supports USB 2.0, ATA 133, SATA 1.5Gb/s

Memory: 2 DDR DIMM Slots: DDR1, DDR2

Support PC3200 (DDR400) / PC2700 (DDR333) /

PC2100 (DDR266), Max. 2GB

IDE: IDE1: ATA 133 / Ultra DMA Mode 6

IDE2: ATA 133 / Ultra DMA Mode 6

Support up to 4 IDE devices

Serial ATA: 2 SATA connectors

Support 1.5Gb/s data transfer rate

Floppy Port: Supports up to 2 floppy disk drives

Audio: 5.1 channels AC’97 Audio

LAN: Speed: 802.3u (10/100 Ethernet), supports Wake-On-LAN

Hardware Monitor: CPU Temperature Sensing

Motherboard Temperature Sensing

CPU Overheat Shutdown to Protect CPU Life

(ASRock U-COP)(see CAUTION 1)

CPU Fan Tachometer

Chassis Fan Tachometer

Voltage Monitoring: +12V, +5V, +3.3V, Vcore

K8 Bridge: Supports CPU upgrade from AMD K7 462-Pin CPU to

AMD K8 754-Pin CPU (see page 9 for details)

PCI slots: 4 slots with PCI Specification 2.3

AGP slots: 2 AGP slots, support 1.5V, 8X/4X AGP card (see CAUTION 2)

1.5V_AGP1 supports for K7 AGP Interface

AGP2 supports for K8 AGP Interface

USB 2.0: 8 USB 2.0 ports:

include 4 ready-to-use USB 2.0 ports on the rear panel,

plus two on-board header supporting 4 extra USB 2.0 ports

(see CAUTION 3)

ASRock I/O: 1 PS/2 mouse port, 1 PS/2 keyboard port,
