49
H310D4-P1
Italiano
Italiano
Connettore uscita audio
Amp 2,5W
(MONO1 a 2 pin)
(vedere pag. 1, n. 4)
Collegare l'altoparlante dello
chassis a questo header.
Connettore recupero
ROM
(ROM_R a 7 pin)
(vedere pag. 1, n. 6)
Questo connettore di recupero
ROM permette a tecnici quali-
cati di ricaricare il rmware nella
ash boot SPI nel caso ci siano
problemi con i dati.
MONO_OUT
+
MONO_OUT
-
1
2
SPI_CS0#
SPI_MOSI
SPI_CS#_R
SPI_MISO
SPI_CLK
+3P3VSB
GND
1
