1.2 Specications
Platform
•
6.7-in x 6.8-in, 17.0 cm x 17.2 cm
CPU
•
Supports 8
th
Generation Intel® Core
TM
Processors (Socket
1151)
•
Supports CPU up to 65W
•
5 Power Phase design
•
Supports Intel® Turbo Boost 2.0 Technology
Chipset
•
Intel
®
H310
Memory
•
Dual Channel DDR4 Memory Technology
•
2 x DDR4 SO-DIMM Slots
•
Supports DDR4 2666/2400/2133 non-ECC, un-buered
memory
•
Max. capacity of system memory: 32GB
•
Supports Intel® Extreme Memory Prole (XMP) 2.0
Expansion
Slot
•
1 x M.2 Socket (Key E), supports type 2230 WiFi/BT module
Graphics
•
Intel® UHD Graphics Built-in Visuals and the VGA outputs
can be supported only with processors which are GPU
integrated.
•
Supports Intel® UHD Graphics Built-in Visuals : Intel®
Quick Sync Video with AVC, MVC (S3D) and MPEG-2 Full
HW Encode1, Intel® InTru
TM
3D, Intel® Clear Video HD
Technology, Intel® Insider
TM
, Intel® UHD Graphics
•
DirectX 12
•
HWAEncode/Decode: AVC/H.264, HEVC/H.265 8-bit,
HEVC/H.265 10-bit, VP8, VP9 8-bit, VP9 10-bit (Decode
only), MPEG2, MJPEG, VC-1 (Decode only)
•
Max. shared memory 1024MB
