ASRock CoreHT Series [10/54] Sata and power connections
![ASRock CoreHT Series [10/54] Sata and power connections](/views2/1692983/page10/bga.png)
10
NOTE.
1. SATA and Power Connections
2. Fan Connection
SATA & Power Connections
ODD
HDD
Connect to ATX5V Power Connector (12)
Connect to SATA Connector (11)
Connect to HDD
Connect to ODD
Connect to SATA Connector
(
13
)
Fan connector
Rotation
+5 V
Ground
item 6
Fan connector
Rotation
+12V
Ground
item 4
