![ASRock CoreHT Series [12/54] System chassis](/img/pdf.png)
ASRock CoreHT Series [12/54] System chassis
![ASRock CoreHT Series [12/54] System chassis](/views2/1692983/page12/bgc.png)
12
27
28
29
30
31
32
1.5 System Chassis
27. Optical Disc Drive
28. Power ON/OFF button with status indicator
29. Drive activity indicator
30. Headphone
31. Microphone
32. USB3.0 ports: USB devices
