DisplayPort
MXM IPC-Q370:
1 x supports max resolution up to 4K@60Hz
(CPU integrated graphics)
4 x supports max resolution up to 4K@60Hz
(MXM Graphics Card)
MXM IPC-Q370-12V:
2 x supports max resolution up to 4K@60Hz
(CPU integrated graphics)
3 x supports max resolution up to 4K@60Hz
(MXM Graphics Card)
MultiDisplay Hexa Display
Ethernet
Ethernet 10/100/1000 Mbps
Controller 1 x Intel
®
I219LM + 1 x Intel
®
I210
Connector 2 x RJ-45
Front I/O
USB 1 x USB2.0
Audio 1 (Mic-In & Line-Out Combo)
DisplayPort 1
Rear I/O
VGA N/A
DVI N/A
HDMI N/A
DisplayPort 1
Ethernet 2
USB 4 x USB 3.0
Audio Jack N/A
Serial N/A
PS2 N/A
Internal
Connector
USB 2 x USB 2.0
LVDS N/A
eDP 1
VGA 1
Serial 1 x COM (RS-232)
SATA 2 x SATA3.0 (6.0 Gb/s)
Parallel N/A
GPIO N/A
SATA PWR
Output Con
N/A
Speaker
Header
N/A
TPM 1 x Header
