Watchdog
Timer
Output Output from super I/O to drag RESETCON#
Interval 256 Segments, 0,1,2…255 Sec
Power
Requirements
Input PWR
MXM IPC-Q370: 19V DC-In Jack (220W for
Quadro P5000)
MXM IPC-Q370-12V:
MXM IPC-Q370-12V: 12V (4-pin plug PWR
cable for maximum 200 watt DC input)
Power On
AT/ATX Supported
-AT : Directly PWR on as power input ready
-ATX : Press button to PWR on after power
input ready
Environment
Temperature
0ºC-50ºC w/GTX1060, 0ºC-45ºC w/
GTX1070, 0ºC-35ºC w/GTX1080
Storage
Temperature
-40ºC – 85°C
