21
SATA Power Connector
Please connect a SATA
(SATA_PWR1)
power cable to this connector.
(see p.9 No. 18)
SPDIF Header SPDIF header, providing
(3-pin SPDIF1)
SPDIF audio output to HDMI
(see p.9, No. 34)
VGA card, allows the system to
connect HDMI Digital TV/
projector/LCD devices. Please
connect the SPDIF connector of
HDMI VGA card to this header.
+5V
ATX Power Connector
Please connect a DC
(4-pin DC_4PIN1)
power supply to this
(see p.9 No. 32)
connector.
1-2 : GND
3-4 : +12V DC Input
(IMB-1222 / IMB-1223)
+12V~+28V DC Input
(IMB-1222-WV / IMB-X1222-WV /
IMB-1223-WV)
1
PIN Signal Name
6 LCD_BLT_VCC
5 LCD_BLT_VCC
4 CON_LBKLT_EN
3 CON_LBKLT_CTL
2 GND
1 GND
GN D
+5 V
+1 2 V
1
GN D
4
2
3
1
Inverter Power Control Wafer
(6-pin BLT_PWR1)
(see p.9 No. 13)
PIN
Signal
Name
PIN
Signal
Name
PIN
Signal
Name
PIN
Signal
Name
PIN
Signal
Name
2
SIO_
GP71
4
SIO_
GP72
6
SIO_
GP73
8
SIO_
GP74
10 GND
1
SIO_
GP75
3
SIO_
GP76
5
SIO_
GP77
7
SIO_
GP80
9
JGPIO_
PWR
Digital Input/Output Pin Header
(10-pin JGPIO1)
(see p.9 No. 9)
1
PIN
Signal
Name
PIN
Signal
Name
PIN
Signal
Name
PIN
Signal
Name
PIN
Signal
Name
PIN
Signal
Name
PIN
Signal
Name
7
GND
6
GND
5
BLT_DW
4
BLT_UP
3
PWRDN
2
GPIO_
VOL_DW
1
GPIO_
VOL_UP
Backlight Volume Control
(7-pin BLT_VOL1)
(see p.9 No. 17)
