PLED (System Power LED):
Connect to the power status indicator on the chassis front panel. The LED
is on when the system is operating. The LED keeps blinking when the sys-
tem is in S1/S3 sleep state. The LED is off when the system is in S4 sleep
state or powered off (S5).
HDLED (Hard Drive Activity LED):
Connect to the hard drive activity LED on the chassis front panel. The LED
is on when the hard drive is reading or writing data.
The front panel design may differ by chassis. A front panel module mainly
consists of power switch, reset switch, power LED, hard drive activity LED,
speaker and etc. When connecting your chassis front panel module to this
header, make sure the wire assignments and the pin assign-ments are
matched correctly.
USB 2.0 Headers Besides two USB 2.0 ports on
(9-pin USB4_5, USB8_9:
the I/O panel, there are two
see p.8, No. 4)
headers on this motherboard.
Each USB 2.0 header can
support two ports.
SATA3 Connectors These two Serial ATA3 (SATA3)
(SATA3_1, SATA3_2: see p.8, No. 5)
connectors support SATA data
cables for internal storage
devices. The current SATA3
interface allows up to 6.0 Gb/s
data transfer rate.
SATA3_1
SATA3_2
DUMMY
GND GND
+B
-B
+A
-A
USB_PWR
USB_PWR
1
Front Panel Audio Header This is an interface for front
(9-pin HD_AUDIO1)
panel audio cable that allows
(see p.8 No. 27)
convenient connection and
control of audio devices.
J_SENS E
OUT2_L
MIC_RET
PRESENCE#
GN D
OUT2_R
MIC2_R
MIC2_L
OUT_RET
1
Содержание
