ASRock IMB-183 [6/40] Specifications
![ASRock IMB-183 [6/40] Specifications](/views2/1693497/page6/bg6.png)
6
1.2 Specications
Form
Factor
Dimensions Mini-ITX (6.7-in x 6.7-in)
Processor
System
CPU
Socket LGA1150 for Intel
®
Core i7/i5/i3/Celeron
(Haswell)
Core
Number
(By CPU, Max 4)
Max Speed (By CPU)
L3 Cache (By CPU)
Chipset H81
BIOS UEFI
Expansion
Slot
PCI 0
Mini-PCIe 1 (PCIe+USB)
mSATA 1 (SATA2+USB)
PCIe 1 (x4)
CFast Card
Socket
0
Memory
Technology
Dual Channel DDR3 1066/1333/1600 MHz
SDRAM
Max. 16GB
Socket 2 x SO-DIMM
Graphics
Controller Intel
®
HD Graphics (By CPU)
VRAM Shared Memory
VGA 0
LVDS 1
HDMI Supports HDMI 1.4a, max resolution 4096x2304
DVI-I 1
DisplayPort 0
Multi Display Yes (Dual Monitor)
Ethernet
Ethernet 10/100/1000 Mbps
Controller GbE LAN1: Intel
®
I217V
Connector 1 x RJ-45
SATA
Max Data
Transfer
Rate
2 x SATA3 (6.0Gb/s)
Rear I/O
VGA 0
DVI-I 1
HDMI 1
DisplayPort 0
Ethernet 1
