7
USB
4 (2 x USB 3.0 compliant, 2 x USB 2.0
compliant)
Audio 2 (Mic-In, Line-Out)
eSATA 1
PS/2 0
Internal
Connector
USB 2 x USB 2.0 headers
LVDS/
Inverter
1
VGA 1
Serial 4 (RS-232)
SATA 2 x SATA3 (6.0Gb/s)
mPCIe 1
Parallel 0
mSATA 1
IrDA 0
GPIO 8-bit 4 x GPI + 4 x GPO
SATA PWR
Output Con
1
Speaker
Header
1
PS2
Keyboard/
Mouse
Header
1
DMIC
Header
1
HDMI_
SPDIF
Header
1
Customer
Solution
Header
1
Watchdog
Timer
Output Output from super I/O to drag RESETCON#
Interval 256 Segments, 0,1,2…255 Sec/Min
Power
Requirements
Input PWR DC 12-19 input
Power On
AT/ATX Supported
AT : Directly PWR on as power input ready
ATX : Press button to PWR on after power
input ready
Environment Temperature 0ºC – 60ºC
