17 : Power Button (PWRBTN1)
18 : Reset Button (RESET1)
19 : USB2.0 Port (USB2_2)
20 :
3.5mm Audio Jack
21 : RJ45 LAN Port (LAN2)
22 : RJ45 LAN Port (LAN1)
23 : Backlight & Amp Volume Control
(BLT_VOL1)
24 : Clear CMOS Header (CLRMOS1)
1-2 : Normal
2-3 : Clear CMOS
25 : Backlight Control Level
(BLT_PWM1)
1-2 : From eDP PWM to CON_LBKLT_CTL
2-3 : From LVDS PWM to CON_LBKLT_CTL
6 : System Panel Header
7 : COM Port Heder
8 : Battery Connector (BAT1)
9 : ATX/AT Mode Select (PWR_JP1)
1-2 : AT Mode
2-3 : ATX Mode
10 : DC Jack Port (DC_JACK1)
11 : USB3.1 Port (USB3_0)
12 : USB3.1 Port (USB3_1)
13 : USB2.0 Connector (USB2_4_5)
14 : HDMI Port (HDMI2)
15 : LPC Header (LPC1)
16 : HDMI Port (HDMI1)
1
: Inverter Power Control Wafer
(BLT_PWR1)
2
: Backlight Power Select
(LCD_BLT_VCC)
(BKT_PWR1)
1-2 : +5V
2-3 : +12V
3 : BL1, BL2
4 : Panel Power Select (LCD_VCC)
(PNL_PWR1)
1-2 : +3V
2-3 : +5V
3-4 : +5V
4-5 : +12V
5 : LVDS Panel Connector
Jumpers and Headers Setting Guide
UTX-115
PIN Signal Name
1 GND
2 GND
3 CON_LBKLT_CTL
4 CON_LBKLT_EN
5 LCD_BLT_VCC
6 LCD_BLT_VCC
1
The terms HDMI
®
and HDMI High-Denition
Multimedia Interface, and the HDMI logo are
trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other
countries.
PIN Signal Name
1 N/A
2 N/A
3 PWRDN
4 GPIO_BLT_UP
5 GPIO_BLT_DW
6 GND
7 GND
1
18
21
23
19
20
22
24
25
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
LAN1
AUDIO1
LVDS1
1
Industrial
PWR_ JP 1
1
LAN2
USB3_0
1
BLT_VOL1
1
BLT_P WR1
DC_JACK1
CLRM OS 1
1
BKT_PWR1
1
PNL_ PW R 1
1
PWRB TN 1
BLT_ PW M1
1
RES ET1
UTX-115
DDR3_B1 (Support DDR3L Only)
DDR3_A1 (Support DDR3L Only)
USB3_1
HDMI2
HDMI1
USB2_2
1
LPC1
USB2_4 _5
1
M.2 KEY E
M.2 KEY B
BL2
1
BL1
1
PANEL1
1
COM1
1
1
1
1
39
40
2
PCIRST#
FRAME
PCICLK
PIN Signal Name PIN Signal Name
2 LCD_VCC 1 LCD_VCC
4 N/A 3 +3V
6 LVDS_A_DATA0# 5 N/A
8 GND1 7 LVDS_A_DATA0
10 LVDS_A_DATA1 9 LVDS_A_DATA1#
12 LVDS_A_DATA2# 11 GND6
14 GND2 13 LVDS_A_DATA2
16 LVDS_A_DATA3 15 LVDS_A_DATA3#
18 LVDS_A_CLK# 17 GND7
20 GND3 19 LVDS_A_CLK
22 LVDS_B_DATA0 21 LVDS_B_DATA0#
24 LVDS_B_DATA1# 23 GND8
26 GND4 25 LVDS_B_DATA1
28 LVDS_B_DATA2 27 LVDS_B_DATA2#
30 LVDS_B_DATA3# 29 DPLVDD_EN
32 GND5 31 LVDS_B_DATA3
34 LVDS_B_CLK 33 LVDS_B_CLK#
36
CON_LBKLT_EN
35 GND9
38 LCD_BLT_VCC 37
CON_LBKLT_CTL
40 LCD_BLT_VCC 39 LCD_BLT_VCC
N/A
+VBAT
GND
1
N/A
RESET#
PWRBTN#
PLED-
PLED+
GND
HDLED-
HDLED+
1
DUMMY
GND
1
N/A
