ASRock J3455-NUC-DL [6/31] Specifications
![ASRock N4200-NUC-DL [6/31] Specifications](/views2/1693712/page6/bg6.png)
6
1.2 Specications
Form
Factor
Dimensions 4.09" x 4.02" (104 x 102mm)
Processor
System
CPU Intel
®
Apollo Lake J3455/N4200/N3350 SoC
Chipset Intel
®
SoC
Expansion
Slot
PCIe
N/A
Mini-PCIe N/A
mSATA N/A
M.2
1 x M.2 2230, Key E (PCIe x1 +USB2.0), 1 x M.2
2242/2260, Key M with SATA3 for SSD
Memory
Technology Dual Channel DDR3L 1867
Max. 16GB
Socket
2 x SO-DIMM
Graphics
Controller Intel
®
Gen9 Graphics DX 11/12, OGL4.3/4.4
VGA N/A
DVI N/A
LVDS N/A
HDMI
Supports HDMI 1.4b, Max. resolution 3840 x
2160@30Hz
DisplayPort
Supports DP 1.2, Max. resolution 4096 x
2160@60Hz
MultiDisplay Triple Display
eDP N/A
Ethernet
Ethernet 10/100/1000 Mbps
Controller 2 x Realtek RTL8111G
Rear I/O
VGA N/A
DVI N/A
HDMI 1
DisplayPort 2
Ethernet 2
USB 2 x USB 3.0
Audio 1 x (Mic-in, Line-out)
Serial N/A
PS/2 N/A
