Jupiter-H110
4 5
English
2.2 Rear View
* ere are two LEDs on the LAN port. Please refer to the table below for the LAN port LED indications.
Activity / Link LED Speed LED
Status Description Status Description
O No Link O 10Mbps connection
Blinking Data Activity Orange 100Mbps connection
On Link Green 1Gbps connection
ACT/LINK LED
SPEED LED
LAN Port
D-SU
BP
ower Input
USB 2.0 Ports
COM Port
Kensington Lock
Audio Line-Out
Antenna Port
HDMI
DisplayPort
LAN port
