Jupiter-H110
2 3
English
Operating
Tempera-
ture
0°C~40°C
Storage
Temp
-40°C~85°C
Humidity
20%~85%
OS
Support
Windows® 7 64-bit & 10 64-bit
Certica-
tions
CB , CE
