ASRock Jupiter-H110 [8/36] English
![ASRock Jupiter-H110 [8/36] English](/views2/1693790/page8/bg8.png)
2 3
English
1.2 Product Specications
Jupiter-H110 Barebone
CPU
Supports Intel® 7
th
/ 6
th
Gen (Kabylake-S/Skylake-S) Core™
Processors
Chipset
Intel® H110
Memory
Supports DDR4 2133MHz, 2 x SO-DIMM slots, Max. 32GB
Graphic
Intel® HD Graphics
Storage
Supports M.2 SATA SSD (2280)
Supports 7mm / 9.5mm 2.5" SATA HDD / SSD
LAN
Realtek® RTL8111GN
Front I/O
4x USB 3.1 Gen1
Rear I/O
1 x HDMI, 1 x DisplayPort, 1 x Ethernet, 4 x USB 2.0,
2 x Audio Jack (Line-in, Line-out), 1 x Serial Port (RS-232),
1 x DC Jack
Dimension
178*178*34mm
Controller
Remote Controller
VESA
Bracket included , supports 75 x 75 and 100 x 100 mm
Weight
1.0kg
