ASRock ROMED8-2T [31/87] English
![ASRock ROMED8-2T [31/87] English](/views2/1694141/page31/bg1f.png)
ROMED8-2T
24 25
English
NVDIMM Power Support
Jumpers
(3-pin NV12V_1)
(see p.6, No. 6)
(3-pin NV12V_2)
(see p.6, No. 43)
(3-pin NV12V_3)
(see p.6, No. 8)
(3-pin NV12V_4)
(see p.6, No. 42)
No support for NVDIMM
power (Default)
Support NVDIMM power
