ASRock ROMED8-2T [8/87] Specifications
![ASRock ROMED8-2T [8/87] Specifications](/views2/1694141/page8/bg8.png)
2 3
English
1.2 Specications
ROMED8-2T
MB Physical Status
Form Factor ATX
Dimension 12'' x 9.6'' (30.5 cm x 24.4 cm)
Processor System
CPU AMD EPYC™ 7002/7001 Series Processor Family
Socket Single Socket SP3 (LGA4094)
Chipset N/A
System Memory
Type - Eight Channel DDR4 memory technology
- Supports DDR4 RDIMM, LRDIMM, and NVDIMM (Jump
Option)
DIMM Size Per
DIMM
- RDIMM: 64GB*, 32GB, 16GB, 8GB
- LRDIMM: 128GB**, 64GB*, 32GB
- NV DIMM: 32GB***
*64GB: wait for the device to be validated
**128GB: wait for the device to be validated
***Wait for the device to be validated
DIMM Frequency - RDIMM: 3200MHz
- LRDIMM: 3200MHz
- NVDIMM: 2666MHz*
*Wait for the device to be validated
Voltage 1.2V
Expansion Slot
PCIe 4.0 x 16 PCIE1: Gen4 x16 link
PCIE2: Gen4 x16 link (shared with M2_1/OCU1/OCU2/
SATA_4_7 by PE8_SEL/PE16_SEL jumpers)
PCIE3: Gen4 x16 link
PCIE4: Gen4 x16 link
PCIE5: Gen4 x16 link
PCIE6: Gen4 x16 link
PCIE7: Gen4 x16 link
Storage
SATA Controller 9 x SATA3 6.0 Gb/s (from 2x mini SAS HD and 1x SATA DOM
port)
M.2 Slot 2(2230/2242/2260/2280/22110, SATA/PCIE(X4))
Ethernet
Interface 10000/1000 /100 /10 Mbps by Intel X550
