ASRock D1521D4I [10/84] English
![ASRock D1521D4I [10/84] English](/views2/1694221/page10/bga.png)
4 5
English
Hardware Monitor
Temperature
- CPU Temperature Sensing
- System Temperature Sensing
- System Inlet Temperature Sensing
Fan
- CPU/Rear/Front Fan Tachometer
- CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by
CPU Temperature)
- CPU/Rear/Front Fan Multi-Speed Control
Volt age
Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM,
1.05V_PCH, +BAT, 3VSB, 5VSB
Support OS
OS Microso® Windows®
- Server 2008 R2 SP1 (64 bit)
- Server 2012 (64 bit)
- Server 2012 R2 (64 bit)
Linux®
- CentOS 6.6 (32 / 64 bit) / 7. 0 (64 bit)
(only supports AHCI mode)
- SUSE Enterprise Linux Server 11 SP3 (32 / 64 bit) /
12 (64 bit)
- FreeBSD 10.1 (32 / 64 bit)
- Fedora Core 22 (64 bit)
- Ubuntu 15.04 (64 bit) / 15.10 (64 bit) (AHCI mode)
-RedHat Enterprise Linux Server 6.6 (32 / 64 bit) / 7.0 (64 bit)
Virtual:
- VMWare ESXi 5.5/ ESXi 6.0
* Please refer to our website for the latest OS support list.
Environment
Temperature Operation temperature: 10°C ~ 35°C / Non operation
temperature: -40°C ~ 70°C
* For detailed product information, please visit our website: http://www.asrockrack.com
is motherboard supports Wake from on Board LAN. To use this function, please make
sure that the “Wake on Magic Packet from power o state” is enabled in Device Manager
> Intel® Ethernet Connection > Power Management. And the “PCI Devices Power On” is
enabled in UEFI SETUP UTILITY > Advanced > ACPI Conguration. Aer that, onboard
LAN1&2 can wake up S5 under OS.
If you install Intel® LAN utility, this motherboard may fail Windows® Hardware Quality
Lab (WHQL) certication tests. If you install the drivers only, it will pass the WHQL tests.
