ASRock D1521D4I [9/84] D15x1d4i series
![ASRock D1521D4I [9/84] D15x1d4i series](/views2/1694221/page9/bg9.png)
D15X1D4I Series
2 3
English
Management
BMC Controller ASPEED AST2400
IPMI Dedicated
GLAN
1 x Realtek RTL8211E for dedicated management GLAN
Features
- Watch Dog
- NMI
- IPMI (Intelligent Platform Management Interface) v.2.0
- Virtual media over LAN function
- KVM over LAN function
Graphics
Controller ASPEED AST2400
VRAM DDR3 16MB SDRAM
Output Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz
Rear Panel I/O
VGA Port 1 x D-Sub
USB 3.0 Port 2
LAN Port
D1521D4I / D1541D4I:
- RJ45: 2x GLAN(by Intel® i210)
- LAN Ports with LED (ACT/LINK LED and SPEED LED)
D1541D4I-2L2T:
- RJ45: 2x 10GLAN(by Intel® X557-AT2 )+ 2x GLAN(by Intel®
i210)
- LAN Ports with LED (ACT/LINK LED and SPEED LED)
UID Button/UID
LED
1
Internal Connector
Auxiliary Panel
Header
1 (include chassis intrusion, location button & LED, front
LAN LED , system fault LED)
TPM Header 1
IPMB Header 1
COM Header 1
Fan Header 4 (1CPU/2Front/1Rear)
ATX Power 1 x (24-pin)
DC-IN Power 1 x (8pin 12V)
System BIOS
BIOS Ty pe 128Mb AMI UEFI Legal BIOS
BIOS Features
- Plug and Play (PnP)
- ACPI 2.0 Compliance Wake Up Events
- SMBIOS 2.8.0 Support
- ASRock Rack Instant Flash
