ROMED6U-2L2T
16 17
English
Please make sure that the carrier
frame with CPU is closely attached to
the rail frame while inserting it.
5
6
Install the carrier frame with CPU. Don’t separate them.
Carrier Frame with CPU
Rail Frame
