1.2 Specications
ROMED6U-2L2T
MB Physical Status
Form Factor microATX
Dimension 9.6'' x 9.6'' (24.4 cm x 24.4 cm)
Processor System
CPU AMD EPYC™ 7002 Series Processor
Socket Single Socket SP3 (LGA4094)
Chipset N/A
ermal Design
Power
280W
System Memory
Type - Six Channel DDR4 memory technology
- Supports DDR4 RDIMM, LRDIMM and NVDIMM
DIMM Size Per
DIMM
- RDIMM: 64GB, 32GB, 16GB, 8GB
- LRDIMM: 128GB, 64GB, 32GB
- NVDIMM: 32GB
DIMM Frequency - RDIMM: 3200MHz
- LRDIMM: 2666MHz
- NVDIMM: 2666MHz
Voltage 1.2V
Expansion Slot
PCIe 4.0 x 16 PCIE7: Gen4 x16 link
PCIE6: Gen4 x16 link
PCIE5: Gen4 x16 link
PCIE4: Gen4 x16 link
Storage
Slimline SLIM1: PCIe Gen4 x8 (Support SATA ) SLIM2: PCIe Gen4 x8
(Support SATA ) SLIM3: PCIe Gen4 x8
SATA 2x 7Pin SATA3 , 12 x SATA3 6.0 Gb/s (from mini SAS HD ,
Gen3)
M.2 Slot 2 (M2_1:2280, M2_2:2260 Support SATA x1 or PCIE x4)
Ethernet
Interface 10G by Intel X710-AT2 ; 1000 /100 /10 Mbps by Intel i210
LAN Controller - 2 x RJ45 10G base-T by Intel® X710-AT2
- 1 x RJ45 1G base-T by Intel® I210-AT2
- 1 x RJ45 Dedicated IPMI LAN port by RTL8211E
- Supports Wake-On-LAN
- Supports Energy Ecient Ethernet 802.3az
- Supports Dual LAN with Teaming function
- Supports PXE
- LAN1 supports NCSI
