EP2C621D8 / EP2C621D8-16R
6 7
English
No. Description
1 2 x 288-pin DDR4 DIMM Slots (DDR4_J1, DDR4_K1)*
2 ATX Power Connector (ATXPWR1)
3 ATX 12V Power Connector (ATX12V2)
4 ATX 12V Power Connector (ATX12V1)
5 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)*
6 CPU1 Fan Connector (CPU1_FAN1)
7 Front Fan Connector (FRNT_FAN1)
8 LGA 3647 CPU Socket (CPU1)
9 Front Fan Connector (FRNT_FAN2)
10 Front Fan Connector (FRNT_FAN3)
11 2 x 288-pin DDR4 DIMM Slots (DDR4_D1, DDR4_E1)*
12 Mini-SAS HD Connector (SATA_0_3)
13 USB 2.0 Header (USB_1_2)
14 Front Fan Connector (FRNT_FAN4)
15 Clear CMOS Pad (CLRMOS1)
16 SATA3 Connector (SSATA_0)
17 SATA DOM Power Jumper (SATAPWR1)
18 Auxiliary Panel Header (AUX_PANEL1)
19 Speaker Header (SPEAKER1)
20 USB 3.0 Header (USB3_3_4)
21 System Panel Header (PANEL1)
22
Mini-SAS HD Connector (SATA/SAS and NVMe) (SAS_NVMEB0_7)
(EP2C621D8-16R Only)
23 Mini-SAS HD Connector (SATA_4_7)
24 Virtual RAID On CPU Header (RAID_1)
25
Mini-SAS HD Connector (SATA/SAS and NVMe) (SAS_NVMEA0_7)
(EP2C621D8-16R Only)
26 PSU SMBus (PSU_SMB1)
27 ME Recovery Jumper (ME_RECOVERY1)
28 BMC SMBus Header (BMC_SMB1)
29 Intelligent Platform Management Bus header (IPMB_1)
30 CPU PECI Jumper (PECI1)
31 TPM Header (TPM1)
32 Chassis ID0 Jumper (CHASSIS_ID0)
