EP2C621D8 / EP2C621D8-16R
2 3
English
Graphics
Controller ASPEED AST2500
VRAM DDR4 16MB
Rear Panel I/O
VGA Port 1 x D-Sub
USB 3.0 Port 2
LAN Port - 2 + 1 x RJ45 Dedicated IPMI LAN port
- LAN Ports with LED (ACT/LINK LED and SPEED LED)
UID Button/
UID LED
1
Internal Connector
Auxiliary Panel
Header
1 (includes chassis intrusion, location button & LED, and front
LAN LED)
TPM Header 1
IPMB Header 1
Fan Header 2 x CPU Fan (4-pin), 4 x system Fan (4-pin)
ATX Power 1 x (24-pin) + 2 x (8-pin)
USB 3.0 Header 1 (supports 2 USB 3.0 ports)
USB 2.0 Header 1 (supports 2 USB 2.0 ports)
SATA DOM 1
M.2 1 (up to 2280, supports PCIE x 4 or SATA x 1)
VROC KEY 1
BMC_SMB1 1
PSU_SMB1 1
NMI Button
Header
1
COM Header 1
Clear CMOS 1 (short pad)
System BIOS
BIOS Ty pe 256Mb AMI UEFI Legal BIOS
BIOS Features - Plug and Play (PnP)
- ACPI 2.0 Compliance Wake Up Events
- SMBIOS 2.8 Support
- ASRock Rack Instant Flash
Hardware Monitor
Temperature - CPU Temperature Sensing
- System Temperature Sensing
Fan - CPU/Front Fan Tachometer
- CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by
CPU Temperature)
- CPU/Front Fan Multi-Speed Control
Voltage Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM,
1.05V_PCH, +BAT, 3VSB, 5VSB
