ASRock EP2C621D8 [16/86] English
![ASRock EP2C621D8 [16/86] English](/views2/1694426/page16/bg10.png)
10 11
English
No. Item Status Description
1 SB_PWR1 Green STB PWR ready
2 CPU_FAN_LED1 Amber CPU1_FAN1 failed
3 FFAN_LED1 Amber FRNT_FAN1 failed
4 FFAN_LED2 Amber FRNT_FAN2 failed
5 FFAN_LED3 Amber FRNT_FAN3 failed
6 FFAN_LED4 Amber FRNT_FAN4 failed
7 BMC_LED1 Green BMC heartbeat LED
8
SAS_SYS_LED1
(EP2C621D8-16R Only)
Green SAS3616W heartbeat LED
9
SAS_IOC_LED1
(EP2C621D8-16R Only)
Red SAS3616W over temperature LED
10 CPU_FAN_LED2 Amber CPU2_FAN1 failed
