ASRock EP2C612D8-2T8R [18/98] English
![ASRock EP2C612D8-2T8R [18/98] English](/views2/1694650/page18/bg12.png)
12 13
English
No. Description
1 2 x 288-pin DDR4 DIMM Slots (DDR4_G, DDR4_H, Blue)
2 ATX 12V Power Connector (ATX12V3)
3 PSU SMBus (PSU_SMB1)
4 ATX Power Connector (ATXPWR1)
5 ATX 12V Power Connector (ATX12V2)
6 2 x 288-pin DDR4 DIMM Slots (DDR4_A, DDR4_B, Blue)
7 Front Fan Connector (FRONT_FAN3)
8 CPU1 Fan Connector (CPU1_FAN)
9 2 x 288-pin DDR4 DIMM Slots (DDR4_C, DDR4_D, Blue)
10 Front Fan Connector (FRONT_FAN4)
11 Front Fan Connector (FRONT_FAN2)
12 SATA SGPIO Connector (SATA_SGPIO1)
13 SATA SGPIO Connector (SATA_SGPIO2)
14 USB 3.0 Header (USB3_2_3)
15 Chassis ID2 Jumper (Chassis_ ID0_2)
16 Chassis ID3 Jumper (Chassis_ ID0_3)
17 Chassis ID1 Jumper (Chassis_ ID0_1)
18 SCU Connector (SCU_1), White
19 Front Fan Connector (FRONT_FAN1)
20 SCU Connector (SCU_0), White
21 SCU Connector (SCU_2), White
22 SCU Connector (SCU_3), White
23 SATA3 Connector (SATA_1), White
24 SATA3 Connector (SATA_0), White
25 SATA3 Connector (SATA_3), White
26 SATA3 Connector (SATA_2), White
27 SATA3 Connector (SATA_5), White
28 SATA3 Connector (SATA_4), White
29 Vertical Type A USB 3.0 (USB3_5)
30 System Panel Header (PANEL1)
31 Speaker Header (SPEAKER1)
32 Auxiliary Panel Header (AUX_PANEL1)
33 ME Recovery Jumper (ME_RECOVERY1)
